HOWO Refrigerated Van Truck Mini Refrigerator Van

Place of Origin : CHINA

Brand Name : CLW

Model NO. : CLW5632tx

Payload : 2ton 3ton 4ton 5ton 6ton

Emission Standard : Euro 2

Transmission Type : Manual

Horsepower : 120HP

Fuel : Diesel

Bearing Capacity : Small

Car Type : Van

Condition : New

Chassis Brand : Dongfeng, Foton, Sinotruk HOWO, FAW, Jmc

Wheel Base : 3308 mm

Box Material : Fiberglass

Refrigeration Brand : Thermoking, Carrier or Chinese Famous Brands

Logo or Pattern : as Per Customer's Request

Insulating Layer : 8cm Polyurethane Foam

Applicable Temperature : -18~0

Gearbox : 5 Forward & 1 Reverse

Tire : 7.00-16

Transport Package : Nude, Container, RO-RO, Bulk

Specification : 5995x2420x3180 mm

Trademark : CLW

Origin : Suizhou, China

HS Code : 8705909990

Production Capacity : 500 Units Per Month

Name : Refrigerator Truck

Model Number : CLW

Payment Terms : 50% Deposit,Balance should be paid before ship out

Supply Ability : 10unit per month

MOQ : 1

Price : 15000-35000 per unit

Contact Now

HOWO 2ton 3ton 4ton 5ton 6ton Refrigerated Freezer Lorry Van Truck Mini Refrigerator Van Cooling Box Truck

Product Description

1. Purpose of the truck : transport frozen fish, meat, fresh vegetables and vaccinum, etc.

2. Main parts of the truck: Refrigerating unit and control system.

3. Features of the truck: International chassis brands and refrigerating unit brands for optional.

Product Specification

General Technical Parameters
Overall Dimension	5995×2420×3180(mm)		Gross Vehicle Weight	4495 (Kg)
Curb Weight	2805 (Kg)		Loading Weight	1495(Kg)
Chassis Specification
Chassis parameters	Chassis Brand		HOWO
	Cabin		Single, Left Hand Driving, with A/C
	Engine	Model	4 Cylinders
		Power	88 KW/120 HP
		Emission standard	EURO II
		Displacement	2780 ml
		Fuel type	Diesel
	Gearbox		5 Forward & 1 Reverse Gear
	Front and Rear Axle load		2.5T/4.5T
	Wheel base		3308(mm)
	Brake System		Oil brake
	Steering Gear		Power Assistant
	Tire		7.00-16, 6 Pieces with 1 Spare Tire
	Maximum speed		90 (km/h)
Superstructure
Van	Box size		4150×2300×2100(mm)
	Material		Fiberglass
	Insulating Layer		8cm Polyurethane Foam
Refrigerator	Brand		Carrier
	Applicable temperature (ºC)		-18~0
Remarks	Part Optional: Ventilation slot Hook External power supply Side door
